EZ Shrink System


EZ Shrink
EZ Shrink
EZ Cool

EZ-SHRINK-EZ3K-KIT

3kw, 1/8-3/4 Capacity, 220V, 20A Single Phase

User adjustable settings.

Includes
  • EZ Shrink Machine
  • Optional 32mm Coil for tooling up to 1-1/4”
  • (2) Bases
  • (1) Cutting Tool Tray
  • (1) Pair of Gloves
  • 12”W x 17.5”D x 31”H
  • Max tool projection over cutter is 12.5” from holder gage line with base installed , base height is 6.5”.

EZ-COOL-EZ3W-KIT

2 Station, 110V, 16A

Includes
  • EZ Cooling Machine
  • (1) Hose Kit
  • (1) Cooling Adapter
  • 16.5”W x 21.88”D x 23”H
  • Coolant Tank Capacity = 5 Gallons

  • Anti-Rust additive recommended


Part Number Includes
EZ-SHRINK-EZ3K Machine Only
EZ-SHRINK-EZ3K-KIT-30 Machine, (2) Base-T30, Gloves, Tool Tray
EZ-SHRINK-EZ3K-KIT-40 Machine, (2) Base-T40, Gloves, Tool Tray
EZ-SHRINK-EZ3K-KIT-50 Machine, (2) Base-T50, Gloves, Tool Tray
EZ-SHRINK-EZ3K-KIT-63A Machine, (2) Base-HSK63A, Gloves, Tool Tray
EZ-SHRINK-EZ3K-KIT-100A Machine, (2) Base-HSK100A, Gloves, Tool Tray
Part Number Includes
EZ-COOL-EZ3W-KIT Base, Shower Head Adapter & Hose
EZ-COOL-SHOWER-HOUSING Replacement Shower Housing
EZ-COOL-HOSE Replacement Hose

Proper cooling is the key to preventing over heating of the tool holders and long life of the H13 tool steel. EZ Cool units uses your shop coolant to returns the holder to a safe to handle temperature in 30 seconds. EZ Shrink Machine is a 3kw, 30 second unit that functions with 1/8-3/4 (3mm-20mm) cutter shanks (carbide only). Pre-programmed and user adjustable EZ Shrink is simple and effective.


EZ Base
EZ-BASE
Part Number Holds
EZ-BASE-T30 BT30, CAT30, ISO30, SK30
EZ-BASE-T40 BT40, CAT40, ISO40, SK40
EZ-BASE-T50 BT50, CAT50, ISO50, SK50
EZ-BASE-HSK032A HSK32A, C & E
EZ-BASE-HSK040A HSK40A, C, E, HSK50F
EZ-BASE-HSK050A HSK50A, C, E, HSK63F
EZ-BASE-HSK063A HSK63A, C, E, HSK80F
EZ-BASE-HSK100A HSK100A, C, E
EZ Base S
EZ-BASE

EZ-BASE-T40 is required to locate any of the EZ-BASE-S below. (Order Separately)

Part Number Holds
EZ-BASE-S037 3/8 Shank
EZ-BASE-S050 1/2 Shank
EZ-BASE-S075 3/4 Shank
EZ-BASE-S100 1" Shank
EZ-BASE-S10 10mm Shank
EZ-BASE-S12 12mm Shank
EZ-BASE-S16 16mm Shank
EZ-BASE-S20 20mm Shank
EZ-BASE-S25 25mm Shank
EZ-BASE-S32 32mm Shank
EZ Cool Extension
EZ-BASE
Part Number
EZ-COOL-EXT Extension Spacer

EZ Tool Tray
EZ-Tray
Part Number
EZ-ROUND-TRAY
EZ Gloves
EZ-BASE
Part Number
EZ-GLOVE Gloves
EZ 32mm Coil
EZ-BASE
Part Number
EZ-SHRINK-EZ3K COIL 32MM 1/2" - 1-1/4" (16-32mm) Coil

EZ Table
EZ-TABLE
  • Dimensions: 48" W x 24" D x 39" H
  • Polyurethane coated solid wooden top (48" x 24" x 1.5" thick)
  • 2 solid steel drawers with ball bearing sliders; 4 wheels (2 locking)
  • Steel frame in graphite finish
Part Number Size
EZ-TOOL-TRAY 48" W x 24" D x 39" H
