CAT40-SD025-160
- Description: CAT40 1/4 SHRINK FIT 6.30
- Catalog Page: 20
- List Price: $514.70
- Inventory Status: Stock
- Item Weight: 3.2 lbs
| Call Out | Data |
|---|---|
| Preset Screw | SCW-ASC-05-23 |
| A | 4.5 |
| D1 | 0.25 |
| D2 | 0.83 |
| D3 | 1.06 |
| L1 | 6.3 |
| L2 | 5.43 |
| L3 | 1.54 |
| Style | 1 |
| Drawing .dwg | DWG |
| Drawing .igs | IGS |
| Drawing .stp | STEP |
Free 3D STP file viewer for Windows can be downloaded here!
