CAT40-SD018-080-12
- Description: CAT40 3/16 SHRINK FIT 3.15 W/ 12MM
- Additional Info: NOSE DIAMETER - 2MM LARGER THAN STD
- Catalog Page:
- List Price: $301.10
- Inventory Status: Stock
- Item Weight: 2.1 lbs
| Call Out | Data |
|---|---|
| Preset Screw | No |
| A | 4.5 |
| D1 | 0.1875 |
| D2 | 0.47 |
| D3 | 0.77 |
| L1 | 3.15 |
| L2 | 2.28 |
| L3 | 4.57 |
| Style | 1 |
Free 3D STP file viewer for Windows can be downloaded here!
